DESCRIPTION
×From the leader in residential indoor air quality, this under-cabinet range hood by Broan-NuTone is built to surpass industry standards with over 50 points of inspection, engineered as a reliable ventilation solution. The durable hood vent is up to 20% more effective at removing pollutants than the leading competitor with power ventilation at 350 Max Blower CFM to capture and remove smoke and odors from the kitchen. The Alta range hood is also up to 44% quieter: 1.5 sones is equivalent to a refrigerator running, so it won't interfere with daily life. The EZ1 Install System allows for a quick and easy 1-person installation, and the ENERGY STAR Certification is both code compliant and provides cost savings. The 2-Level LED lighting modules and a 3-Speed tap touch control make cooking a breeze.
SPECIFICATIONS
ו ALT2 Series
• 7-inch round
• 20% More Effective: Trust in the Broan-NuTone brand to more effectively remove pollutants in your kitchen than the leading competitor, with strong airflow at 350 Max Blower CFM
• Up to 44% Quieter: With sound equivalent to a refrigerator running, this vent hood is up to 44% quieter than competition at 1.5 sones on working speed
• One Person Installation: With the included EZ1 brackets it's an easy install for a single person in half the time, both professional and DiYers
• Both ENERGY STAR certified and Title 24 compliant (with electric ranges only), this kitchen hood is energy efficient and code compliant
• Bright 2-level, heat resistant LED modules (included) to enhance your cooking experience
• Easy-to-clean, fully enclosed bottom with 2 dishwasher-safe high efficiency micro filters
• The seamless tap-touch controls are backlit and adjust the 3-speed blower and 2 level lighting
• Convertible to accommodate either top or rear venting applications or non-ducted operation using charcoal filters, which are sold separately (Filter Model HPF30)
• Range hood is installed as hardwired or with an optional power cord kit (HCK44; sold separately)
• Can be used with optional Universal make-up air damper MD6TU, MD8TU or MD10TU to replace air exhausted out of the house only when the hood is turned ON, helping with ventilation to keep your home fresh while reducing energy consumption
• Can be installed for ADA Compliance with the purchase of model HAWSK3 low voltage wiring and wall switch kit
• Filter Type: Micro Mesh
• Lighting Type: LED
• Sound Level (Sones): 1.5
• Light Bulb Wattage: 5
• Light Bulbs Included
• Bulb (Recommended Type): Integrated LED Module
• Light Levels: 2
• Material: Stainless Steel
• Ductless Recirculation Capable
• Ductless Filter Or Kit Included
• Switch Control Type: Capacitive Touch
• Country of Origin: China
• Rated Amps: 0.8
• Capture Efficiency: 98.1%
• Wattage: 168
