DESCRIPTION
×This Frigidaire Gallery 24" built-in dishwasher features EvenDry™system, 24-hour delay start, 8 wash programs and can fit up to 14 place settings. Serving utensils and tools are mealtime-ready with Store-More™ removable third rack, which offers easy loading and unloading access.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Type
Built-In
Color
Black Stainless
Manufacturer Color
Black Stainless Steel
Place Settings
14
Tub Material
Stainless Steel
Silence Rating
49 dB
Cycle Information
Number of Cycles
8
Wash Cycles
• PowerPlus™ (Heavy)
• Normal
• Quick Wash (30-Min.)
• Favourite
• China Crystal
• Rinse Only
• Energy Saver Plus
• Upper Rack Wash Only
• Normal
• Quick Wash (30-Min.)
• Favourite
• China Crystal
• Rinse Only
• Energy Saver Plus
• Upper Rack Wash Only
Options
• Heat, No Heat Dry
• Hi-temp Wash
• Nsf® Certified Sanitize Rinse
• Delay Start
• Hi-temp Wash
• Nsf® Certified Sanitize Rinse
• Delay Start
Features
Technologies
• Fully-Integrated Express-Select®
• OrbitClean® Wash Arm
• DishSense™ Technology
• AquaSurge™ Technology
• SilentDesign™ Sound Package
• Nylon TufRacks™
• OrbitClean® Wash Arm
• DishSense™ Technology
• AquaSurge™ Technology
• SilentDesign™ Sound Package
• Nylon TufRacks™
Delay Start Information
1-24 Hours
Delay Start
Yes
3rd Rack System
Yes
Control Lock
Yes
Cutlery Tray
No
Filtration System
Yes
Silverware Basket
Yes
Wi-Fi
No
Additional Information
• Digital Display
• Door Latch, Stay-Put Door Hinge Design
• Direct Feed Wash System
• 5 Wash Levels
• 5 Wash Speeds
• LED Cycle Complete Floor Beam Indicator
• Stemware?Rack
• Fold-Down Tines
• 2 Cup Shelves
• 2 Stemware Grips
• Adjustable Rack
• 3-Piece Split SpaceWise® Silverware Basket
• 2 Full Rows Fold-Down Tines
• 2 Small Items Cover
• Third-Level Rack (Single Tray)
• Door Latch, Stay-Put Door Hinge Design
• Direct Feed Wash System
• 5 Wash Levels
• 5 Wash Speeds
• LED Cycle Complete Floor Beam Indicator
• Stemware?Rack
• Fold-Down Tines
• 2 Cup Shelves
• 2 Stemware Grips
• Adjustable Rack
• 3-Piece Split SpaceWise® Silverware Basket
• 2 Full Rows Fold-Down Tines
• 2 Small Items Cover
• Third-Level Rack (Single Tray)
Electrical Information
Information
• 15 A
• 120 V
• 60 Hz
• 120 V
• 60 Hz
Certifications and Approvals
Energy Star Certified
Yes
NSF® Certified
Yes
ADA Compliant
No
Dimensions
Class Width
24"
Width
23.75 inch(es) / 60.33 cm
Height (Min.)
33.75 inch(es) / 85.73 cm
Depth (Without Handle)
24.25 inch(es) / 61.6 cm
Additional Dimensions
• Depth (To Tub Flange): 22-1/2"
• Depth with Door Open 90 Degrees: 50-1/4"
• Cutout Dimensions: Height (Min.) 34", Height (Max.) 35-3/4", Width (Min.) 24", Depth (Min.) 24"
• For more information refer to dimension manual
• Depth with Door Open 90 Degrees: 50-1/4"
• Cutout Dimensions: Height (Min.) 34", Height (Max.) 35-3/4", Width (Min.) 24", Depth (Min.) 24"
• For more information refer to dimension manual
Shipping Dimensions
Weight
91.01 lb(s) / 41.28 kg
Warranty
Warranty
Limited 1 year parts and labor
UPC
UPC#
12505115547
