DESCRIPTION
×Crisp and brown with less oil* and less hassle. KitchenAid® Single Wall Ovens with Air Fry Mode include a dishwasher-safe air fry basket with plenty of capacity for large batches. A built-in thermometer takes the guesswork out of cooking meat, fish, poultry, casseroles and more to the perfect degree of doneness every time. *When compared to deep frying.
FEATURES
×
Features
EVEN-HEAT™ TRUE CONVECTION OVEN
Provides consistent heating and even cooking on all racks with a unique bow-tie shaped design and convection fan that helps ensure the most even baking.
SATINGLIDE™ ROLL-OUT EXTENSION RACK
Allows easy loading and features an easy-grip handle, giving you the confidence when cooking with large or heavy dishes.
SPECIFICATIONS
×
Specifications
General
Fuel Type
Electric
Color
Black Stainless
Manufacturer Color
Black Stainless Steel with PrintShield™
Total Capacity
5.0 cu. ft.
Main Oven Capacity
5.0 cu. ft.
Oven Specifications
Technologies
• Even-Heat™ True Convection
• Air Fry Technology
• WiFi; App; Remote Access; Voice Controlled
• Air Fry Technology
• WiFi; App; Remote Access; Voice Controlled
Air Fry
Yes
Clock
Yes
Convection
Yes
Digital Temperature Display
Yes
Oven Light
Yes
Self-Cleaning
Yes
Wi-Fi
Yes
Additional Information
• Built-In Thermometer
• Interior Color: Blue
• Light Type: Halogen
• Broiler Element Power: 4000W
• Convection Element Power Watts: 3,200
• Convection Functions: Bake; Broil; Convection Conversion
• 3 Oven Racks
• Oven Rack 3 Type: Gliding Roll-Out
• Hidden Bake Element
• Bake Element Power: 2800W
• 2 Oven Lights
• 6 Rack Guides
• 2 Bake Elements
• Interior Coating: Porcelain
• Light Control: Oven Light Touch Pad
• 1 Broil Elements
• Interior Color: Blue
• Light Type: Halogen
• Broiler Element Power: 4000W
• Convection Element Power Watts: 3,200
• Convection Functions: Bake; Broil; Convection Conversion
• 3 Oven Racks
• Oven Rack 3 Type: Gliding Roll-Out
• Hidden Bake Element
• Bake Element Power: 2800W
• 2 Oven Lights
• 6 Rack Guides
• 2 Bake Elements
• Interior Coating: Porcelain
• Light Control: Oven Light Touch Pad
• 1 Broil Elements
Electrical Information
Information
20 A, 60 Hz
Accessories
Optional
W11406621, W11366049
Dimensions
Class Width
30"
Width
29.75 inch(es) / 75.57 cm
Height
28.75 inch(es) / 73.03 cm
Depth
27.13 inch(es) / 68.9 cm
Additional Dimensions
• Depth Closed Excluding Handles: 24.5"
• Depth Closed Including Handles: 27.13"
• Depth With Door Open 90 Degrees: 46.75"
• Cutout Depth: 24.0"
• Cutout Height: 28.0"
• Cutout Width: 28.5"
• Depth Closed Including Handles: 27.13"
• Depth With Door Open 90 Degrees: 46.75"
• Cutout Depth: 24.0"
• Cutout Height: 28.0"
• Cutout Width: 28.5"
Weight
149.01 lb(s) / 67.59 kg
Shipping Dimensions
Width
34.81 inch(es) / 88.42 cm
Height
30.75 inch(es) / 78.11 cm
Depth
30.81 inch(es) / 78.26 cm
Weight
159.99 lb(s) / 72.57 kg
UPC
UPC#
883049667492
