DESCRIPTION
×This 36” electric cooktop features Downdraft, an integrated ventilation system that doesn’t require a separate hood. A 10-inch Even-Heat™ Ultra element provides versatility for both high-and low-temperature cooking, and has multiple simmer settings. And with a 3-speed fan with 300 CFM exhaust rating, the venting can keep up withyour culinary feats.
FEATURES
×
Features
SPECIFICATIONS
×
Specifications
General
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Center Front Element: 3,200 W
• Center Rear Element: 1,200 W
• Left Front Element: 1,300 W
• Left Rear Element: 1,800 W
• Right Rear Element: 3,000 W
• Center Rear Element: 1,200 W
• Left Front Element: 1,300 W
• Left Rear Element: 1,800 W
• Right Rear Element: 3,000 W
Burner/Element Size
• Center Front Element: 10"
• Center Rear Element: 6"
• Left Front Element: 6"
• Left Rear Element: 8"
• Right Rear Element: 12"/9"
• Center Rear Element: 6"
• Left Front Element: 6"
• Left Rear Element: 8"
• Right Rear Element: 12"/9"
Elements
Smoothtop
Surface Features
• CookShield Finish for Glass Surface
• Stainless Steel Knobs
• Pure Color Ceramic-Glass Surface
• Stainless Steel Knobs
• Pure Color Ceramic-Glass Surface
Features
Technologies
• Even-Heat™ Ultra Element
• Even-Heat™ Element
• Even-Heat™ Element
Downdraft Ventilation
Yes
Additional Information
• 300 CFM Exhaust Rating
• 3-Speed Fan Control
• 12"/9" Double-Ring Element
• Convertible to Duct-Free Ventilation
• Power-On Indicator Light
• Hot-Surface Indicator
• 3-Speed Fan Control
• 12"/9" Double-Ring Element
• Convertible to Duct-Free Ventilation
• Power-On Indicator Light
• Hot-Surface Indicator
Electrical Information
Information
• 120 V /240 V
• 60 Hz
• 40 A
• 60 Hz
• 40 A
Dimensions
Class Width
36"
Width
36.31 inch(es) / 92.23 cm
Height
3.63 inch(es) / 9.21 cm
Depth
22.06 inch(es) / 56.04 cm
Weight
73 lb(s) / 33.11 kg
Shipping Dimensions
Width
41.5 inch(es) / 105.41 cm
Height
23.81 inch(es) / 60.48 cm
Depth
26.44 inch(es) / 67.15 cm
Weight
78 lb(s) / 35.38 kg
Warranty
Warranty
1 Year Parts and Labor
UPC
UPC#
883049415932
